Deutsch Connectors, MIL SPEC Deutsch Connector Applications, Defense / Aerospace, Industrial / Hermetic, Communications
Our company offer Deutsch connectors for a large spectrum of applications. Please see below some of the products
we offer, and contact us for more info or a quote.
MIL SPEC Deutsch Connectors for Defense / Aerospace
Environmentally sealed interconnection devices for critical circuits
for outer space, aircraft communications, ground-based vehicles, and military operations.
|
|
MIL-C-26482 Series II
|
MS347*
|
Circular, Miniature, Bayonet
|
|
MIL-C-38999 Series I
|
MS2746*
|
Circular, Miniature, Bayonet
|
|
MIL-C-38999 Series III
|
D38999/2*
|
Circular, Sub-miniature, Threaded
|
|
MIL-C-38999 Series IV
|
D38999/4*
|
Circular, Sub-miniature, Breach
|
|
MIL-C-83723 Series III
|
M83723/*
|
Circular, Miniature, Bayonet
|
|
MIL-C-81703 Series I, II, III
|
MS313*, 314*,342*,346*
|
Circular, Sub-Miniature, Push Pull
|
|
MIL-C-81511 Series III & IV
|
M81511/4* & /5*
|
Circular, Sub-Miniature,
Bayonet, High Density
|
|
Mil-Spec Composite
|
|
MIL-T-81714 Series II
|
M81714/6*
|
Composite termination system
|
|
MIL-C-38999 III
|
D38999/2* (Class J & M)
|
Sub-Miniature, Threaded,
Composite
|
|
MIL-C-29600 Series I & II
|
M29600/*
|
Sub-Miniature, Threaded, High
Density Composite
|
|
AFLC8810310
|
ABC
|
Rectangular, High Density,
Composite
|
|
Contacts & Terminations
|
|
MIL-C-39029
|
MIL-C-39029
|
Contacts
|
|
Deutsch Standards
|
|
Various
|
DM, DS, RE, RSM, TJ
|
Consult Factory
|
|
MIL-STD-1760
|
|
D38999/31J*20N3
|
ACT98W*20PN-****
|
Type 3 Composite Lanyard Plug
|
|
Deutsch Industrial Connectors
Environmentally sealed, heavy-duty electrical interconnection devices for critical circuits for truck, bus,
construction, railway, agricultural, off-highway and specific O.E.M. applications.
COMMON CONTACT SYSTEM
Deutsch's wide array of solid or stamped and formed contacts allows common tooling, processing, and
terminations for the widest application with any Deutsch IPD connector series. Stamped and formed
styles include 7 sizes each of pin and socket contacts that terminate 12 AWG to 20 AWG. Solid style
contacts terminate wire from 6 AWG to 24 AWG and are available in 6 sizes each of pin and socket contacts. Extended pins are available for PCB applications
Solid Contacts
Stamped & Formed Contacts
DEUTSCH DRB SERIES BULKHEAD CONNECTOR
High-density thermoplastic bulkhead connector with silicone rubber grommets suitable for on- and off
-highway applications. Available in 48-, 60- and 102-pin configurations utilizing Deutsch's common
contact wire termination system for size 6- to 20-AWG wire; accepts both signal and power wires in the
same connector. Allows single-person installation from one side of the bulkhead with a single sturdy
jackscrew and hex wrench. Flanges, plugs, receptacles, and color-coded wedges keyed to prevent
mismatching and confusion. Choice of solid or stamped and formed terminals; copper alloy with nickel finish--gold optional. Thermoplastic sealing plugs.
60-pin DRB Bulkhead Connector
102-pin DRB Bulkhead Connector
DEUTSCH DT SERIES TRANSPORTATION CONNECTORS
For cable-to-cable applications on the engine or transmission, under the hood, on the chassis or in the
cab for reliability and performance in harsh environmental conditions. General purpose connectors with
thermoplastic housings and silicone seals employed with either solid-copper or nickel-plated stamped
and formed crimp type terminals which require no special tools for insertion or removal. Environmentally
sealed; available in 2, 3, 4, 6, 8 & 12-pin arrangements for size 18 through 14 AWG wire.
Integral connector latches
Rugged thermoplastic housings
Silicone seals
Crimp contacts--gold or nickel, solid or stamped
Current Rating of 13 amps all contacts
Fail safe secondary locks
Hand insertable/removable contacts
Data transmission or power distribution terminals
Engine Compartment Rated
Tactile & audible coupling feedback
Meets most harness design requirements
Superior environmental seal
Seals .088 to .145 dia. insulation
No special tools required
Low installation costs
For more industrial Deutsch connectors, please contact us.
Deutsch Connectors for Hermetic Applications
Electrical interconnection devices for severe conditions and harsh environments...in outer space, underground,
undersea, in vacuum chambers and laboratories, for military and commercial hermetic applications, sensor monitoring and aircraft engines.
815 Series (MIL-C-81511 Series qualified Subminiature)
RSM 5130, RSM 5150 Subminiature performs to MIL-C-81571
MIL-C-83723 DL, DBC 30 94603 Miniature
RTK 30H and RTK 50H High density subminiature performs to MIL-C-81511
MIL-C-81703 RBC 70 and DBC 70 miniature
MIL-C-38999, DJT Series I, DJL Series II, DTS Series III*, DIV Series IV
MIL-DTL-38999 Series III Filters
MIL-C-5015 DH02 meets req. of MIL-C-39029 subminiature
DBC 50 High density miniature MIL-C-26482 Series II Miniature
MIL-C-24308 D-Subminiature Hermetic Receptacles
MIL-DTL-83723: Deutsch DEC Series
Deutsch Connectors for Communications Applications
DSS Series of RF Connectors - High Durability 7/16 RF Connector in both Plug and Receptacle
configurations combines high durability with superior inter-modulation performance for both flexible and semi-rigid cable types.
DPP RF Push/Pull Plugs and Cables - RF Push/Pull Plugs feature quick connect/disconnect coupling design to accommodate common N-Type receptacles.
CPP Composite Push Pull Connectors - General purpose environmentally sealed corrosion-proof connector with push-pull convenience.
59000-6000 Threaded Composite - Environmentally sealed triple-start threaded coupling connector with EMI/RFI shielding.
Power and Light - Integrated Power and Light Fiber Optic Solutions, environmental, shielded.
RJ45 Test Port - Environmental, EMI/RFI shielded, durable corrosion resilient composite connector.
HPC Composite Threaded - High Performance cylindrical connector provides environmental sealing for applications that do not require RFI/EMI shielding.
DFP Fluid Power - Composite threaded connector offering standardized pin identification, EMI shielding, intermountability on existing products, and a repairable backshell system.
BVD Composite Threaded - General purpose composite threaded connector that meets density, environmental, current and signal requirements in most applications.
|
